Design of three-axis direct drive structure.Z-axis direct drive lift structure.Z-axis with built-in pneumatic balance configuration, maximum load of 10kg.XY adopts high-precision linear guide rail, and Z-axis adopts anti creep cross

roller guide rail.XY adopts a marble base, with travel dimensions customized according to customer requirements.
